How to Manage a Red Hat MicroShift Cluster with Shipa

Run Kubernetes clusters in environments with tight resource constraints (e.g. edge / IoT devices) without spending a lot of time on deployments and governance.

For developers working with low-resource environments that nevertheless wish to harness the full advantages of Kubernetes, the open-source Red Hat MicroShift project and Shipa (an application-as-code platform you can spin up for free) offer a rather compelling pairing. In this article, I’ll take you through the steps of using MicroShift to set up a lightweight Kubernetes distribution, and then manage the same cluster using the “free forever” version of Shipa Cloud.

But first, why MicroShift? A research project started by Red Hat, MicroShift is built for running Kubernetes clusters in environments with tight resource constraints, such as edge and IoT devices. It’s a memory-optimized lightweight flavor of OpenShift/Kubernetes, and currently supports Fedora, RHEL, and CentOS Linux distributions. Shipa fits in here by helping solve some of the usual problems faced by developers and platform operators. It lets developers focus on what they’re good at and want to do (building applications) and reduces the time platform operators spend on deployments and governance. Onboarding MicroShift to Shipa offers some nice benefits by making it possible to manage multiple clusters from an administration and operations perspective.

According to Shipa documentation, the Red Hat OpenShift/MicroShift Kubernetes distribution is not officially supported, which led me to investigate how to run MicroShift on Shipa Cloud. Internally, MicroShift uses the CRI-O lightweight container runtime, and I wanted to test its compatibility beyond the containerd and Docker solutions suggested by Shipa’s documentation (don’t worry, this solution works!).

Getting Set Up

First, let’s provision a self-managed MicroShift cluster on any cloud VM (AWS/Azure/GCP) or even a local machine. The steps are almost the same for any cloud service provider (I’m using Azure for this example):

1. Provision a VM with minimum resources of 2 vCPU and 4 GB RAM.

2. Install Red Hat MicroShift.

3. Update the kube-api certificate to include an IP and DNS name.

4. Connect to Shipa Cloud and deploy an app.

1) Provisioning

As of now, MicroShift officially runs on Fedora, RHEL, and CentOS. For our use case, we will create a VM with CentOS on Azure. Provisioning is done via Pulumi.

Install Pulumi

You can install Pulumi with a one-line bash, using this code snippet:

curl -fsSL https://get.pulumi.com | sh

Create a Pulumi Account

Once you have installed the binary, create a Pulumi account, and then an access token to access the project and stack. A stack is an isolated, independently configurable instance of a Pulumi program. Stacks are commonly used to denote different phases of development (such as development, staging, and production) or feature branches (such as feature-x-dev). A project can have as many stacks as you need.

You can also sign in using GitHub or GitLab as well. Once you have logged in, go to Settings and create the access token which enables you to programmatically access the Pulumi organization and stack.

Use Pulumi and YAML

Pulumi supports YAML files, which makes it easy to provision your infrastructure. The IaC for creating Azure VM is described in the following YAML file:

name: azure-vm

runtime: yaml

description: A minimal Azure Native Pulumi YAML program

configuration:

prefix:

type: String

default: tfvmex

resources:

microshift:

type: azure:core:ResourceGroup

properties:

location: West US

mainVirtualNetwork:

type: azure:network:VirtualNetwork

properties:

addressSpaces:

- 10.0.0.0/16

location: ${microshift.location}

resourceGroupName: ${microshift.name}

internal:

type: azure:network:Subnet

properties:

resourceGroupName: ${microshift.name}

virtualNetworkName: ${mainVirtualNetwork.name}

addressPrefixes:

- 10.0.2.0/24

mainNetworkInterface:

type: azure:network:NetworkInterface

properties:

location: ${microshift.location}

resourceGroupName: ${microshift.name}

ipConfigurations:

- name: testconfiguration1

subnetId: ${internal.id}

privateIpAddressAllocation: Dynamic

mainNetworkSecurityGroup:

type: azure:network:NetworkSecurityGroup

properties:

location: ${microshift.location}

resourceGroupName: ${microshift.name}

securityRules:

- name: SSH

priority: 100

direction: Inbound

access: Allow

protocol: Tcp

sourcePortRange: '*'

destinationPortRange: '22'

sourceAddressPrefix: '*'

destinationAddressPrefix: '*'

- name: Kubernetes-API

priority: 101

direction: Inbound

access: Allow

protocol: Tcp

sourcePortRange: '*'

destinationPortRange: '6443'

sourceAddressPrefix: '*'

destinationAddressPrefix: '*'

- name: Kubelet

priority: 102

direction: Inbound

access: Allow

protocol: Tcp

sourcePortRange: '*'

destinationPortRange: '10250'

sourceAddressPrefix: '*'

destinationAddressPrefix: '*'

mainVirtualMachine:

type: azure:compute:VirtualMachine

properties:

location: ${microshift.location}

resourceGroupName: ${microshift.name}

networkInterfaceIds:

- ${mainNetworkInterface.id}

vmSize: Standard_B2s

storageImageReference:

publisher: cognosys

offer: centos-8-3-free

sku: centos-8-3-free

version: latest

storageOsDisk:

name: microshiftos

caching: ReadWrite

createOption: FromImage

managedDiskType: Standard_LRS

plan:

name: centos-8-3-free

product: centos-8-3-free

publisher: cognosys

osProfile:

computerName: microshift

adminUsername: microshift

adminPassword: Password1234!

If the configuration is set, fire up the provisioning with the “pulumi up” command, and it will be up within the time it takes to have a coffee break:

pulumi up

2) Install MicroShift on CentOS

Once you have your VM provisioned, the next step is to install MicroShift on the machine. There are a few binaries that need to be installed first on the OS level. The whole installation has been consolidated into a shell script and can be used right away.

The script will add an IP to the host file and then install the cri and cri-o lightweight container runtime. After that, it will install MicroShift and the OC CLI to interact with the cluster:

# Install script for https://github.com/redhat-et/microshift

# Can be installed using:

# curl -sfL https://raw.githubusercontent.com/nerdalert/microshift-installer/main/microshift-install.sh | sh -s -

#!/bin/sh

set -e

set -o noglob

# If the node does not have a FQDN

export IP=$(hostname -I | awk '{print $1}')

echo -e "- Adding the following host entry to /etc/hosts if it doesn't exist: $(hostname) $IP"

if ! grep --quiet "$IP $hostname" /etc/hosts; then

echo $IP $(hostname) | sudo tee -a /etc/hosts

echo -e "\xE2\x9C\x94 Done\n"

# Detect the OS and install cri-o

uname=$(uname -r)

if echo "$uname" | grep -Eq 'fc'; then

echo "Fedora OS detected"

echo '- Installing cri-o container runtime...'

sudo dnf module enable -y cri-o:1.21

sudo dnf install -y cri-o cri-tools

sudo systemctl enable crio --now

echo -e "\xE2\x9C\x94 Done"

sleep 15

elif echo "$uname" | grep -Eq 'el'; then

echo 'CentOS/RHEL OS detected'

echo '- Installing cri-o container runtime...'

sudo curl -L -o /etc/yum.repos.d/devel:kubic:libcontainers:stable.repo https://download.opensuse.org/repositories/devel:/kubic:/libcontainers:/stable/CentOS_8_Stream/devel:kubic:libcontainers:stable.repo

sudo curl -L -o /etc/yum.repos.d/devel:kubic:libcontainers:stable:cri-o:1.21.repo https://download.opensuse.org/repositories/devel:kubic:libcontainers:stable:cri-o:1.21/CentOS_8_Stream/devel:kubic:libcontainers:stable:cri-o:1.21.repo

sudo dnf install -y cri-o cri-tools

sudo systemctl enable crio --now

echo -e "\xE2\x9C\x94 Done"

else

echo "No supported OS detected (requires CentOS or Fedora) exiting install.."

exit

echo '- Installing Microshift packages...'

sudo dnf copr enable -y @redhat-et/microshift

sudo dnf install -y microshift

sudo systemctl enable microshift --now

echo -e "\xE2\x9C\x94 Done"

# wait for the kubeconfig file to become available

echo "Wating for cri-o pods to initiate.."

count=1

kubeconf=/var/lib/microshift/resources/kubeadmin/kubeconfig

until sudo test -f $kubeconf; do

if [ $count -gt 180 ]; then

echo -e "\u274c kubeconfig not found in $kubeconf, there may be an issue with the installation"

break

count=$((count + 1))

sleep 1

done

cricount=1

while ! sudo crictl ps | grep -q 'flannel'; do

cricount=$((cricount + 1))

if [ $cricount -gt 180 ]; then

echo "timed out waiting on cri-o pods"

break

sleep 1

done

# check for kubectl

if ! command -v oc &> /dev/null

then

echo -e "Warning: the oc binary was not found, install it with:\n"

curl -O https://mirror.openshift.com/pub/openshift-v4/$(uname - m)/clients/ocp/stable/openshift-client-linux.tar.gz

sudo tar -xf openshift-client-linux.tar.gz -C /usr/local/bin oc kubectl

echo "pods are initiating may take a couple of minutes depending on resources.."

echo "- Installation complete, view the pods with the following:"

echo "########################################################################"

echo "mkdir ~/.kube"

echo "sudo cat /var/lib/microshift/resources/kubeadmin/kubeconfig > ~/.kube/config"

3) Update kube-api Server Certificate

Since we’re setting up a self-managed MicroShift cluster on a VM with a public IP and trying to connect with Shipa Cloud, we’re likely to get an “Unable to connect to the server: x509: certificate..” error. To mitigate this issue, we need to regenerate the certificate that includes the VM IP and DNS label. To make this operation successful, we need to install OpenSSL libraries.

As an initial step, we’ll check out the IP and DNS names mapped in the certificate. To do this, we need to have OpenSSL installed on the system:

sudo dnf install openssl

cd /var/lib/microshift/certs/kube-apiserver/secrets/service-network-serving-certkey/

# Execute to find the currently mapped IP and DNS names

openssl x509 -in tls.crt -text | grep "X509v3 Subject Alternative

Name:" -A1

Note down the output from the above command. Then, create a new config, amended with the new IP and DNS:

cat <

[req]

req_extensions = v3_req

distinguished_name = req_distinguished_name

[req_distinguished_name]

[ v3_req ]

basicConstraints = CA:FALSE

keyUsage = nonRepudiation, digitalSignature, keyEncipherment

subjectAltName = @alt_names

[alt_names]

DNS.1 = kubernetes

DNS.2 = kubernetes.default

DNS.3 = kubernetes.default.svc

DNS.4 = localhost

DNS.5 = kube-apiserver

DNS.6 = microshift.example.com

DNS.7 = IP.1 = 127.0.0.1

IP.2 = 10.114.101.2

IP.3 = 10.43.0.1

IP.4 = 192.168.1.209

IP.5 = 192.168.1.212

IP.6 =

EOF

Execute the below commands to regenerate the TLS certificate:

openssl genrsa -out tls.key 2048

openssl req -new -key tls.key -subj "/CN=kube-apiserver" -out tls.csr -config api.conf

openssl x509 -req -in tls.csr -CA /var/lib/microshift/certs/ca-bundle/ca-bundle.crt -CAkey /var/lib/microshift/certs/ca-bundle/ca-bundle.key -CAcreateserial -out tls.crt -extensions v3_req -extfile api.conf -days 1000

rm -f tls.csr

openssl x509 -in tls.crt -text # Check that the new IP address is added

We now have a kube-api certificate with the VM public IP and DNS label. Next, let’s connect to Shipa Cloud and deploy some apps.

4) Connect to Shipa Cloud

Because Red Hat OpenShift/MicroShift is not officially supported by Shipa, making it work requires a workaround.

To connect our cluster to Shipa Cloud, first provide the VM Public IP in the Kubernetes Control Plane in this format: https://:6443.

Next, execute the generated command on the cluster. This will create the Shipa CRD and related components.

Run this command to view all Shipa components running on MicroShift:

oc get all -n shipa

Now let's deploy a simple Nginx pod via Shipa Cloud.

In the first attempt at deployment, you will get an error saying that the Shipa nginx service is not able to start. This is because shipa-ingress-nginx is deployed with the type “LoadBalancer”, and isn’t able to get an external IP to continue. This is a common error when deploying a self-managed cluster on a VM. To resolve this, edit shipa-ingress-nginx and change the type to NodePort.

oc edit svc shipa-ingress-nginx -n shipa

#Patching the service type to NodePort oc patch svc shipa-ingress-nginx -n shipa -p '{"spec":{"type":"NodePort"}}'

Now the Nginx deployment will run.

Conclusion

Through this article, we learned how to set up a MicroShift cluster and manage it through Shipa Cloud. This experiment with a lightweight cluster makes it evident that Shipa can support the Red Hat MicroShift flavor of Kubernetes, which runs the CRI-O container runtime under the hood.
